ELE5000-28MDP
Edmonson Ticket Issuing Machine
Main features
- Side frame supporting matrix printer
- Fitting size for Edmonson Tickets (ISO/IEC 15457 TFC.0,30x66mm)
- Stepping motor and photosensors ticket positioning
- In line 28 motor dot printer mechanism
- Single or dual way dispenser configuration
- Cutter blades with keen self-sharpening
- Capturing function with shedder ticket device
- ELE2000 reader/encoder module usage
- Microprocessor based electronics
- SMD low consumption electronic circuits
- Communication by means RS232 and USB
- Overall description
- Card/Ticket specifications
- Environmental
- Dot Printer
Outline dimensions
214(H) x 468,5(L) x 160(W) mm
Weight
8 Kg (Approximately)
Electronics
Specific PCB
Ticket motion
Stepping motor
Transport method
Belt
Ticket sensors
Photosensors
Output interface
Ethernet (optional), RS232 and USB
Power requirements
+24V DC +/-10% 10A
Display
128x64 graphic
Length
66.00 mm
Width
33.00 mm
Thickness
From 0.20 to 0.30 mm
Operating temperature
From -10 to + 65°C
Storage temperature
From -30 to + 85°C
Relative humidity
From 20 to 80% (No condensation)
Printing method
Dot matrix impact
Dot per line
28dpi
Resolution
80 dpi
Front configuration
User defined (Default 7x5)
Characters set
ASCII standard, International
